ATLASdoor
The Future of Industrial Safety
ATLASdoor is a vision-based safety system that controls access to robotic cells based on real-time conditions.
It determines when a process is active, when it is complete, and when the environment is safe for entry. Access is not timed. It is verified.
This removes operator judgment from safety-critical moments and replaces it with system-level control.
_gif.gif)
Access Control, Enforced
The door remains closed while hazardous activity is underway. Entry is only permitted once the system confirms the cell is clear.
Real-Time Verification
Machine vision continuously monitors the process and makes decisions based on actual conditions inside the cell.
Designed for Integration
Built to work within existing robotic environments, safety architectures, and control systems.
Key Information
Highlights
-
High-speed barrier door for robot cells, conveyors & automated machinery
-
2 m/s travel speed; rated 120 cycles/hour, 5 million cycles
-
Category 3 safety logic with Allen-Bradley safety switches and light curtain
-
Self-supporting floor frame; soft bottom edge flush to floor
-
Modular design: inline/perpendicular gearbox, top/bottom/front/rear motor mounts
-
Predictive-ready cycle/torque monitoring port
Design Mandates
ISO Standards
-
ISO 13849-1 – Safety-related parts of control systems
-
ISO 13855 – Positioning of safeguards relative to approach speed
-
ISO 13857 – Safety distances to prevent reach into hazard zones
-
ISO 10218 – Safety requirements for industrial robots and integration
-
ISO 12100 – General principles for machine safety and risk reduction
-
ISO 11161 – Safety of integrated manufacturing systems
-
ISO 14119 – Design and selection of interlocking devices
Warranty
-
Motor/Brake/Gearbox – 5 years
-
Mechanical & Electrical Components – 2 years
-
Extended coverage available upon request
Speed & Duty
-
Opening/Closing: 2 m/s standard (6.56 ft/s)
-
Duty cycle: 120 cycles per hour (continuous)
-
Design life: 5,000,000+ cycles
-
Operating temperature: -40 °C … +66 °C
Safety Features
Function | Device | Rating/Action |
|---|---|---|
Manual Release | Lever Handle | Safe Egress on Power Loss |
Interlock Logic | Safety Relay/PLC | Category 3 |
Position Sensing | Dual Prox Switches (Top & Bottom) | Prevent Over-travel |
Obstruction Sensing | Light Curtain + Impact Logic | Door Stops on Detect |
Hazard Isolation | Barrier Door | Physically Blocks Reach Per ISO 13857 |
Why It Matters
Most safety systems rely on timing, assumptions, or manual confirmation.
That model breaks under pressure.
ATLASdoor removes that dependency. It evaluates conditions directly and enforces access without relying on human intervention. The result is consistent safety performance, regardless of operator behavior or production pace.
Application
Containment
Controls exposure to heat, debris, fumes, and active equipment.
Restricted Access
Prevents premature or unauthorized entry into hazardous zones.
Compliance
Supports established safety standards and safeguarding requirements.
Continuity
Maintains workflow without introducing manual steps or delays.
